Panasonic LUMIX DMC-GX80 User Manual

93
4. Focus, Brightness (Exposure) and
Colour tone Settings
Adjusting Focus Automatically
By setting the optimum Focus Mode or Auto Focus Mode for the subject or recording
condition, you can let the camera automatically adjust focus in various scenes.
1
Set the [Focus Mode] to [AFS], [AFF] or [AFC].
• The Focus Mode will be set. (P95)
2
Press 2 ().
3
Press 2/1 to select AF Mode and then press
[MENU/SET].
• The Auto Focus Mode will be set. (P97)
4
Press the shutter button halfway.
• Auto Focus will be activated.
• The focus indication is displayed as [ ] in a dark environment, and focusing may take
longer than usual.
• If the camera detects stars in the night sky after displaying [ ], Starlight AF will be
activated. When focus is achieved, the focus indication [ ] and AF areas in focus are
displayed.
(Detection with Starlight AF works only for approximately 1/3 of the centre area of the
screen.)
Focus
When the subject is
focused
When the subject is not
focused
Focus indication A On Blinks
AF area B Green —
Sound Beeps 2 times —
6060603.53.53.5
B
A
LOW
LOW
STAR

Panasonic LUMIX DMC-GX80 Specifications

General

Camera Type	Mirrorless
Sensor Type	Live MOS
Effective Pixels	16 megapixels
Image Processor	Venus Engine
Image Stabilization	5-axis in-body image stabilization
Built-in Flash	Yes
External Flash	Hot shoe
Dimensions	122 x 70.6 x 43.9 mm
Sensor Size	17.3 x 13.0 mm (Four Thirds)
ISO Sensitivity	200-25600
Autofocus System	Contrast AF
Viewfinder	Electronic (2.764M dots)
Screen	3.0" LCD (1.040K dots), tilting touchscreen
Video Recording	4K UHD at 30p/24p
Shutter Speed	1/16000 to 60 sec
Continuous Shooting	8 fps (AFS/MF), 6 fps (AFC)
Connectivity	Wi-Fi
Battery Life	Approx. 290 shots (CIPA standard)
Battery	Rechargeable Li-ion Battery Pack, 7.2V, 1025mAh
Weight	426 g (body only)
