Panasonic LUMIX DMC-GX80 User Manual

1. Before Use
16
∫ Lens
1 Lens surface
2 Zoom ring (P150)
3 Contact point
4 Lens fitting mark (P32)
5 Focus ring (P107)
6 [O.I.S.] switch (P146)
•
The interchangeable lens (H-FS12032) does not have a focus ring, but you can use manual
focus by operating the camera. (P106)
H-FS12032 H-FS35100
H-H020A H-FS14140
•
The interchangeable lens (H-H020A) utilises a lens drive system to realize a compact and
bright F1.7 lens. As a result, sound and vibration may occur during focus operation, but this is
not a malfunction.
• Operating sounds will be recorded when auto focus is performed during motion picture
recording. It is recommended to record with [Continuous AF] (P170) set to [OFF], if the sound
of operation bothers you. (P166) Also, it is not possible to set the Focus Mode to [AFC] or
[AFF]. (P95)
2
34
1
512
34
15 34
1526 3 4

Panasonic LUMIX DMC-GX80 Specifications

General

Camera Type	Mirrorless
Sensor Type	Live MOS
Effective Pixels	16 megapixels
Image Processor	Venus Engine
Image Stabilization	5-axis in-body image stabilization
Built-in Flash	Yes
External Flash	Hot shoe
Dimensions	122 x 70.6 x 43.9 mm
Sensor Size	17.3 x 13.0 mm (Four Thirds)
ISO Sensitivity	200-25600
Autofocus System	Contrast AF
Viewfinder	Electronic (2.764M dots)
Screen	3.0" LCD (1.040K dots), tilting touchscreen
Video Recording	4K UHD at 30p/24p
Shutter Speed	1/16000 to 60 sec
Continuous Shooting	8 fps (AFS/MF), 6 fps (AFC)
Connectivity	Wi-Fi
Battery Life	Approx. 290 shots (CIPA standard)
Battery	Rechargeable Li-ion Battery Pack, 7.2V, 1025mAh
Weight	426 g (body only)
