Panasonic LUMIX DMC-GX80 User Manual

7. Recording Motion Pictures
172
3
Set the cropping start frame.
A Cropping start frame
• When making settings for the first time, a cropping start
frame of size 1920k1080 is displayed. (After setting the
cropping start frame and end frame, the start frame and
end frame that you set immediately before will be
displayed.)
• The camera will remember the frame position and size
even when the camera is turned off.
4
Repeat step 3, and then set the cropping end
frame.
B Cropping end frame
• The setting of the Auto Focus Mode switches to [š].
(The eye to be in focus is not indicated.)
Button operation Touch operation Description of operation
3/4/2/1 Touching Moves the frame
Pinch out/
Pinch in
Enlarges/reduces the frame
(The range of settings allowed is
from 1920k1080 to 3840k2160.)
[DISP.] [Reset]
Returns the position of the frame to
the centre and its size to the
default setting.
[MENU/SET] [Set]
Decides the position and size of
the frame
5HVHW
ュリヴヱハ
6HW
A
5HVHW
ュリヴヱハ
6HW
B

Panasonic LUMIX DMC-GX80 Specifications

General

Camera Type	Mirrorless
Sensor Type	Live MOS
Effective Pixels	16 megapixels
Image Processor	Venus Engine
Image Stabilization	5-axis in-body image stabilization
Built-in Flash	Yes
External Flash	Hot shoe
Dimensions	122 x 70.6 x 43.9 mm
Sensor Size	17.3 x 13.0 mm (Four Thirds)
ISO Sensitivity	200-25600
Autofocus System	Contrast AF
Viewfinder	Electronic (2.764M dots)
Screen	3.0" LCD (1.040K dots), tilting touchscreen
Video Recording	4K UHD at 30p/24p
Shutter Speed	1/16000 to 60 sec
Continuous Shooting	8 fps (AFS/MF), 6 fps (AFC)
Connectivity	Wi-Fi
Battery Life	Approx. 290 shots (CIPA standard)
Battery	Rechargeable Li-ion Battery Pack, 7.2V, 1025mAh
Weight	426 g (body only)
