Panasonic LUMIX DMC-GX80 User Manual

45
2. Getting Started/Basic Operations
Temporarily changing the items assigned to the front/rear dials ([Dial Operation
Switch])
You can temporarily change the items assigned to the front/rear dials using the function
button to which [Dial Operation Switch] is assigned.
•
You can set the items to be assigned temporarily to the front/rear dials in [Dial Operation Switch
Setup] in [Dial Set.] in the [Custom] menu. (P46)
1 Set a function button to [Dial Operation Switch]. (P58)
•
The following step is an example in which [Dial Operation Switch] is assigned to [Fn1].
2 Press [Fn1].
•
A guide will be displayed showing the items temporarily
assigned to the front/rear dials.
• If no operations are performed, the guide will disappear in
a few seconds.
3 Rotate the front/rear dials while the guide is
displayed.
•
The settings of the items assigned to the dials will change.
4 Press [MENU/SET] and set.
•
You can also complete this step by performing either of the operations below:
– Press the shutter button halfway
– Press the rear dial
– Press [Fn1]
• Items that are temporarily assigned to the front/rear dials can be used only while the guide
(step
2) or setting screen (step 3) is displayed.
989898
0
ISOISOISOISO
WBWBWBWB
WBWBWBWBWBWBWBWBWBWBWB
AWB
AWB
ISOISOISOISO

Panasonic LUMIX DMC-GX80 Specifications

General

Camera Type	Mirrorless
Sensor Type	Live MOS
Effective Pixels	16 megapixels
Image Processor	Venus Engine
Image Stabilization	5-axis in-body image stabilization
Built-in Flash	Yes
External Flash	Hot shoe
Dimensions	122 x 70.6 x 43.9 mm
Sensor Size	17.3 x 13.0 mm (Four Thirds)
ISO Sensitivity	200-25600
Autofocus System	Contrast AF
Viewfinder	Electronic (2.764M dots)
Screen	3.0" LCD (1.040K dots), tilting touchscreen
Video Recording	4K UHD at 30p/24p
Shutter Speed	1/16000 to 60 sec
Continuous Shooting	8 fps (AFS/MF), 6 fps (AFC)
Connectivity	Wi-Fi
Battery Life	Approx. 290 shots (CIPA standard)
Battery	Rechargeable Li-ion Battery Pack, 7.2V, 1025mAh
Weight	426 g (body only)
