30 Focus Ring Button (P35, P41)
31 Aperture Ring Button (P31)
32 Diopter Adjustment Dial (P28)
33 [USB] Socket (5pin) (P98)
34 [DC IN] Socket (P14)
35 [AV OUT/REMOTE] Socket (P95)
36 Terminal Door
37 Strap Eyelet (P20)
38 Card Slot (P16)
39 Card Door (P16)
40 Battery Door (P12)
41 Battery Door Open/Close Lever
(P12)
42 Tripod Receptacle
ª Battery Charger/AC Adaptor
(P10, P14)
1 [AC IN] Terminal
2 Battery Attachment Part
3 [POWER] Indicator
4 [CHARGE] Indicator
5 [DC OUT] Terminal
3230 31
33
34
35
36
38
37
39
C
L
O
S
E
O
PEN
40 41 42
3
4
5
2
1
