Panasonic Lumix DMC-LX5 User Manual

- 137 -
Advanced (Recording pictures)
∫ About AF area selection
You can select the AF area by pressing 3 (FOCUS) when [Ø] is selected.
It is also possible to switch to AF area selection screen by pressing 1 when AF Mode is
selected with 3/4.
•
You can set from the quick menu. (P30)
1 Press 3/4/2/1 to move the AF area.
•
You can set to arbitrary position of the screen. (It cannot be set to
edge of the screen)
• After moving the AF area, press [DISPLAY] to return it to the
center.
2 Rotate the rear dial to change the size of AF area.
Rear dial right: Enlarge
Rear dial left: Shrink
•
It can be changed to 4 different sizes of “spot” A, “normal” B,
“large” C, and “extra large” D.
3 Press [MENU/SET] to set.
•
You can also press the rear dial to set.
Note
•
AF area cannot be moved and its size cannot be changed during motion picture recording.
• Set the size of AF area to “normal”, “large”, or “extra large” when it is hard to focus using the
“spot”.
• The spot metering target can also be moved to match the AF area when using [Ù].
• Position of the AF area will return to initial state when the camera is set to Intelligent Auto
Mode, When the Sleep Mode is activated, or When this unit is turned off.
• AF is performed at the center position with a large frame instead of the area selected by AF
area selection in the following cases:
– While using Digital Zoom
– When it is hard to focus due to darkness
A
B DC

Panasonic Lumix DMC-LX5 Specifications

General

Megapixel	10.1 MP
Camera type	Compact camera
Sensor type	CCD
Image stabilizer	Yes
Total megapixels	11.3 MP
Image sensor size	- \
Supported aspect ratios	3:2, 4:3, 16:9
Maximum image resolution	3648 x 2736 pixels
Still image resolution(s)	480 x 480, 640 x 360, 640 x 424, 640 x 480, 1536 x 1536, 1600 x 1200, 1920 x 1080, 1920 x 1920, 2048 x 1360, 2048 x 1536, 2304 x 2304, 2560 x 1920, 2736 x 2736, 3072 x 2304, 3328 x 1872, 3648 x 2736, 3968 x 2232
Digital zoom	4 x
Optical zoom	3.8 x
Extra/Smart zoom	6.7 x
Focal length range	5.1 - 19.2 mm
Number of diaphragm blades	5
Number of aspheric elements	3
Lens structure (elements/groups)	10/9
Aperture range (F-F)	2 - 3.3
Camera shutter speed	60 - 1/4000 s
Focal length (35mm film equivalent)	24 - 90 mm
Normal focusing range	0.5 - ∞ m
Auto focusing (AF) modes	Continuous Auto Focus, Selective Auto Focus
Macro focusing range (tele)	0.3 - ∞ m
Macro focusing range (wide)	1 - ∞ m
Light metering	Centre-weighted, Spot
ISO sensitivity	80, 100, 200, 400, 800, 1600, 3200, 6400, 12800, Auto
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
Light exposure control	Program AE
Light exposure correction	± 3EV (1/3EV step)
Camera shutter interval	0.5 s
Flash modes	Auto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash range (tele)	0.3 - 4.4 m
Flash range (wide)	0.8 - 7.2 m
Scene modes	Beach, Candlelight, Children, Close-up (macro), Cuisine, Fireworks, Night landscape, Night portrait, Panorama, Party (indoor), Portrait, Self-portrait, Snow, Sports, Sunset, Landscape (scenery)
Image editing	Crop, Resizing
Photo effects	-
White balance	Auto, Cloudy, Daylight, Flash, Shade
Shooting modes	Aperture priority, Auto, Manual, Movie, Program, Scene, Shutter priority
Camera playback	Movie, Single image, Slide show, Thumbnails
Self-timer delay	2, 10 s
Camera file system	DCF 2.0, Exif 2.3
Playback zoom (max)	16 x
On Screen Display (OSD) languages	DEU, ENG, ESP, FRE, ITA, JPN
Video resolutions	320 x 240, 640 x 480, 1280 x 720 pixels
Motion JPEG frame rate	30 fps
Video formats supported	AVCHD, M-JPEG
Maximum video resolution	1280 x 720 pixels
Analog signal format system	NTSC, PAL
Internal memory	40 MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display resolution (numeric)	460000 pixels
USB version	2.0
Product color	Black
Battery voltage	3.6 V
Battery capacity	1250 mAh
Battery life (CIPA standard)	400 shots
Cables included	AC, AV, USB
Bundled software	PHOTOfunSTUDIO 5.0 HD Edition, / SILKYPIX Developer Studio 3.1 SE, / QuickTime / Adobe Reader

Weight and Dimensions

Depth	43 mm
Width	109.7 mm
Height	65.5 mm
Weight	233 g
Weight (including battery)	271 g
