- 9 -
Before Use
14 Cursor buttons
15 Aspect ratio selector switch (P43)
16 Microphone (P105)
17 Zoom lever (P54)
18 Motion picture button (P44, 104)
19 Flash open switch (P67)
20 Hot shoe cover (P11, 196, 198, 199)
21 Mode dial (P41)
22 Shutter button (P49)
23 Camera ON/OFF switch (P25)
24 [HDMI] socket (P179, 181)
25 [AV OUT/DIGITAL] socket (P177, 184,
186, 190)
26 Lens ring front (P201, 203)
27 Lens barrel
3/[FOCUS] button (P51, 61, 137)
4/Function button (P32)
Assign Menu to 4 button. It is convenient to register a Menu that is used often.
[FILM MODE]/[QUALITY]/[METERING MODE]/[WHITE BALANCE]/[AF MODE]/
[I.EXPOSURE]/[GUIDE LINE]/
[ REC AREA]/[REMAINING DISP.]/[FLASH]/
[AUTO BRACKET]/[ASPECT BRACKET]
2/Self-timer button (P74)
1/ISO (P75)
In these operating instructions, the cursor buttons are described as shown in the
figure below or described with 3/4/2/1.
e.g.: When you press the 4 (down) button
or Press 4
15 16 17 18
19 20 21 22 23
