- 7 -
Before Use
Names of the Components
1 Flash (P51)
2Lens (P167, 168)
3 Self-timer indicator (P58)
AF Assist Lamp (P111)
4 LCD monitor (P49, 163)
5 [MENU/SET] button (P18)
6 [DISPLAY] button (P49)
7 [Q.MENU] (P24)/Delete (P47) button
8 [REC]/[PLAYBACK] selector switch
(P20)
9 Motion picture button (P33, 77)
10 Cursor buttons
: /Exposure compensation (P59)/
Auto Bracket (P60)/White Balance
fine adjustment (P100)
: /Macro Mode (P56)
AF Tracking (P36, 103)
: /Self-timer button (P58)
: /Flash setting button (P51)
In these operating instructions, the cursor buttons are described as shown in the
figure below or descr bed with ///.
e.g.: When you press the (down) button
or Press
123
4
675
10
