7. Metering/Exposure/ISO Sensitivity
DVQX2068 (ENG)
73
In [M] mode (Manual Exposure mode), you can take pictures by manually
setting the aperture value and shutter speed.
In default settings, the ISO sensitivity is set to [AUTO].
As a result, the ISO sensitivity will be adjusted according to the aperture
value and shutter speed.
Exposure compensation can also be used when ISO sensitivity is set to
[AUTO].
1
Set the mode dial to [M].
2
Set the aperture value and
shutter speed.
≥Rotate to set the aperture
value A, and to set the shutter
speed B.
3
Start recording.
0
If the correct exposure is not achieved
when the shutter button is pressed halfway, the aperture value and the
shutter speed blink red.
Available Shutter Speeds (Sec.)
Manual Exposure Mode
[MECH.] [B] (Bulb, max. approx. 30 minutes), 60 to 1/8000
[EFC] [B] (Bulb, max. approx. 30 minutes), 60 to 1/2000
[ELEC.] [B] (Bulb, max. approx. 60 seconds), 60 to 1/8000
