Panasonic LZ2 - Page 118

Mini VRF SYSTEM
Remote Controller Functions
5 - 22
3. Remote Controller Servicing Functions
5
<Function of CZ-RTC4>
List of Servicing Functions
Functions Description Button operation Reset operation Unit status
Test run
Operation with forced
thermostat ON
Press the
button.
Current operation
is maintained.
Sensor
temperature
display
Temperature display
from each sensor
Servicing
check display
Alarm history display
Simple
settings
Filter lifetime, operating
mode priority, central
control address, and
other settings
When settings
are made from a
remote controller,
the indoor unit
where that remote
controller is
connected stops.
Detailed
settings
System address, indoor
unit address, central
control address, and
other settings
Auto address
Auto address setting
based on command
from the wired remote
controller
Automatic reset
Entire system
stops.
Address
change
Change of indoor unit
address
Press the
button.
Press and hold the button for
4 seconds or longer.
Press and hold the and
buttons for 4 seconds or longer.
Press and hold the and
buttons for 4 seconds or longer.
Press and hold the , and
buttons for 4 seconds or
longer.
Press and hold the and
buttons for 4 seconds or longer.
Press and hold the and the
timer operation buttons for 4
seconds or longer.
Press and hold the and the
timer operation buttons for 4
seconds or longer.
<Procedure of CZ-RTC5B>
(1) Keep pressing the
When the appears on the LCD display, the state of the sensor unit can be checked in the following
method.
, and
buttons simultaneously for 4 or more seconds.
The “Maintenance func” screen appears on the
LCD display.
(3)
(2)
Press the or button to see each
menu.
Select “Sensor unit info.” on the LCD display and
press the
Select “0. ECONAVI info.” on the LCD display and
press the button.
button.
Select the “Unit no.” by pressing the
or
button for changes.
Then press the button.
Display sensor information of the unit.
Refer to the information by pressing the
or
button.
■
ECONAVI info.
Unit no. Code no. Data
Sel. Next
20:30 (THU)
11
12
10
0001
0000
0002
1
Maintenance func
Sel. Page [ ] Confirm
20:30 (THU)
0. ECONAVI info.
1. Outdoor unit error data
2. Service contact
3. RC setting mode
ECONAVI info.
Sel. [ ] Check
20:30 (THU)
Setting info.
System settings
Status info.
Sensor unit info.
ECONAVI info.
Unit no. Code no. Data
1000
0000
2000
11
10
12
Sel. Next
20:30 (THU)
1
ECONAVI Display
