Mini VRF SYSTEM
Outdoor Unit Repair Procedures
3
1. Removing Panels
Be sure to turn off the power before maintenance. When the power is turned off, wait for
5 minutes without any work. Then start working.
• Remove the front panel (remove 2 screws).
(1) Front panel removal
(2) Cover A removal
• Remove the cover A (remove 1 screw).
Fig. 1
Front panel
Cover A
CAUTION
