xiii
< Whether or not to use R32 refrigerant leakage detection sensor >
• According to the type of diagrams shown in Fig. 2, it is necessary to install R32 refrigerant
leakage detection sensor if the installation space is within the range of using R32 refrigerant
leakage detection sensor.
• As to installation method of R32 refrigerant leakage detection sensor, refer to Technical Data.
• When connecting R32 refrigerant leakage detection sensor, group connection with a remote
controller is not possible. Be sure to prepare a remote controller for each indoor unit.
The refrigerant charge amount compared with the floor area of the room is roughly as follows:
NOTE
In the case of connecting R32 refrigerant leakage detection sensor :
• For systems using R32 refrigerant, this unit is equipped with a refrigerant leak detector for
safety. To be effective, the unit must be electrically powered at all times after installation, other
than when servicing.
00_330344_2WAY_Eng.indb 13 2020/12/21 11:26:34
Here is one of an example shown below. The following diagram is subject to change according to the type of the connected
indoor units. Refer to each indoor unit Service Manual.
Example:
0
0.0
5.0
10.0
15.0
20.0
20 40 60 8010 30 50 70 90 100
0
0.0
5.0
10.0
15.0
20.0
20 40 60 8010 30 50 70 90 100
0
0.0
5.0
10.0
15.0
20.0
20 40 60 8010 30 50 70 90 100
4-Way Cassette 60 × 60
Fig. 2
Type 15
Refrigerant charge amount (kg)
Floor area of the room (m²)
Type 22
Refrigerant charge amount (kg)
Floor area of the room (m²)
Use of R32 refrigerant leakage detection sensor
Nonuse of R32 refrigerant leakage detection sensor
Type 28
Refrigerant charge amount (kg)
Floor area of the room (m²)
Use of R32 refrigerant leakage detection sensor
Nonuse of R32 refrigerant leakage detection sensor
Use of R32 refrigerant leakage detection sensor
Nonuse of R32 refrigerant leakage detection sensor
