Mini VRF SYSTEM
Test Run
7 - 17
7
4. Auto Address Setting
CZ-RTC5B (High-spec wired remote controller)
(1) Keep pressing the
, and buttons
simultaneously for 4 or more seconds.
The “Maintenance func” screen appears on the LCD display.
Maintenance func
1. Outdoor unit error data
2. Service contact
3. RC setting mode
4. Test run
Sel. Page [ ] Confirm
20:30 (THU)
(2) Press the or button to see each menu.
If you wish to see the next screen instantly, press the or
button.
Select “7. Simple settings” on the LCD display and press the
button.
(3) The “Simple settings” screen appears on the LCD display.
Select the “Unit no.” by pressing the or button for
changes.
The indoor unit fan operates only at the selected indoor unit.
(4) Press the
button when “Unit no.” is selected, and then
select “YES” and press
button to return to normal remote
controller mode.
Simple settings
Unit no. Code no. Set data
011-1 0001
Sel. Next
20:30 (THU)
20:30 (THU)
START
[]
Maintenance func
5. Sensor info.
6. Servicing check
8. Detailed settings
20:30 (THU)
7. Simple settings
CZ-RTC4 (Timer remote controller)
(1) Press and hold the
button and button for 4 seconds or
longer (simple settings mode).
(2) “ALL” is displayed on the remote controller.
(3) Next, press the
button.
(4) The address is displayed for 1 of the indoor units which is
connected to the remote controller. Check that the fan of that indoor
unit starts and that air is discharged.
(5) Press the
button again and check the address of each indoor
unit in sequence.
(6) Press the
button again to return to normal remote controller
mode.
Number changes to indicate which
indoor unit is currently selected.
Indoor unit address
Number changes to indicate which
indoor unit is currently selected.
Indoor unit address
