Mini VRF SYSTEM
Control Functions - Outdoor unit
1 - 30
1
11. Detailed Settings in EEPROM of Outdoor
Unit
DN Item Setting No.
78
Outdoor silent mode as input setting "Valid" or "Invalid"
from the indoor unit remote controller
0=Invalid (P)
1=Valid
(For details, see Section "4. Outdoor Unit Fan Control (6)")
81
Outdoor unit capacity
(Setting when the data is not stored in the EEPROM.
Do not change under normal conditions.)
0=Invalid 21=224 23=280
A3 The minimum operating time 1 until defrosting
20=20 minutes 21=21 minutes ,,,,,
35=35 minutes (P) ,,,,, 40=40 minutes
41 - 90=Never use
(For details, see Section "8. Defrost Control (4)")
A8 The minimum operating time 3 until defrosting
0=0 minute , 10=10 minutes ,,,,,
90=90 minutes (P) ,,,,, 120=120 minutes
-1=Invalid
(For details, see Section "8. Defrost Control (3)")
CA The defrost detection temperature 3 setting
-3=-3°C (P) , -6=-6°C , -9=-9°C ,,,,, -30=-30°C
(For details, see Section "8. Defrost Control (3)")
E1
Discharge air temperature control with thermostat OFF
additional time
-20=-20 minutes -19=-19 minutes ,,,,,
0=0 minute (P) ,,,,, 10=10 minutes
(For details, see Section "5. Outdoor Unit CCU Control (5)")
EF Indoor unit auto restart setting
0=No control (P)
1=capable of auto restart
2=incapable of auto restart
Never use the DN code unlisted in the following table. (P) : Factory preset mode
1-1. Outdoor Unit Control PCB
CN-RC
CN-MOV1
CN-SILENT
SA1
CN-OC
CN-EMG
CN-ROM
CN-TERMINAL
CN-LPS
AP
MODE
LED2
LED1
SW2
SW1
CN-HPS
RUN
TEST
CN-EXG
STOP
CN-TO
CHK
CN-MOV2
A.ADD
DEF
CN-OIL
SW4
SW3
CN-SCT
CN-EXL
CN-DISCH
JP001
