Mini VRF SYSTEM
Outdoor Unit Maintenance Remote Controller
4
3. Ordinary Display Controls and Functions
Â
XX-YY R.C.
Displays the outdoor unit sub-bus address which is
currently selected.
XX = Outdoor system address on main bus line (1 – 30)
YY = Outdoor unit sub-bus address (1 – 8)
“1” appears when there is only 1 outdoor unit.
Locations where
À
,
Á
, and
Â
are displayed as
shown in Fig. 1.
01: <No. of connected indoor units>
4 units connected
<Sample displays>
02: <Unit Nos. 1, 2, 3 and 4 are
connected>
Fig. 1
A
A
LED
1
2
3
A
