CAUTION
THE STRIPED FRAME INDICATES THE PRIMARY CIRCUIT TO DISTINGUISH THE PRIMARY
FROM THE SECONDARY CIRCUIT.
PAY ATTENTION NOT TO RECEIVE AN ELECTRIC SHOCK DURING REPAIR AND SERVICE OF
THE PRODUCTS.
IMPORTANT SAFETY NOTICE:
COMPONENTS IDENTIFIED WITH THE MARK HAVE THE SPECIAL CHARACTERISTICS FOR SAFETY.
WHEN REPLACING ANY OF THESE COMPONENTS, USE ONLY THE SAME TYPE.
Transistor
POWER C.B.A.
Integrated Circuit
Connector
ADDRESS INFORMATION
Q1111 B-4
IC1101 B-3
IC1102 B-5
P1101 B-1
P1103 B-5
To Next Page
