Panasonic PT-DZ21K2

Chapter 4 Settings — [DISPLAY OPTION] menu
ENGLISH - 115
Note
f The optimal setting varies depending on the output setting of the connected external device. Refer to the operating instructions of the
external device regarding the output of the external device.
f The data for Plug and play will change when the setting is changed. Refer to “List of compatible signals” (x page 209) for a resolution that
supports plug and play.
Setting [EDID MODE]
1) Press as to select [DVI-D IN].
2) Press the <ENTER> button.
f The [DVI-D IN] screen is displayed.
3) Press as to select [EDID MODE].
4) Press the <ENTER> button.
f The [DVI-D EDID MODE] screen is displayed.
5) Press qw to switch [EDID MODE].
f The items will switch each time you press the button.
[DEFAULT] Standard setting.
[SCREEN FIT]
*1
Changes EDID data according to the [SCREEN FORMAT] setting.
[USER] Sets the [RESOLUTION] and [VERTICAL SCAN FREQUENCY] items to EDID.
*1 Only for PT-DZ21K2, PT-DS20K2, PT-DZ16K2
f When [DEFAULT] or [SCREEN FIT] is selected, proceed to Step 10).
6) Press the <ENTER> button.
f The [RESOLUTION] screen is displayed.
7) Press asqw to select [RESOLUTION].
f Select [1024x768p], [1280x720p], [1280x768p], [1280x800p], [1280x1024p], [1366x768p], [1400x1050p],
[1440x900p], [1600x900p], [1600x1200p], [1680x1050p], [1920x1080p], [1920x1080i], or [1920x1200p].
8) Press the <ENTER> button.
f The [VERTICAL SCAN FREQUENCY] screen is displayed.
9) Press qw to select [VERTICAL SCAN FREQUENCY].
f Select [60Hz], [50Hz], [30Hz], [25Hz], or [24Hz] when [1920x1080p] is selected for [RESOLUTION].
f Select [60Hz], [50Hz], or [48Hz] when [1920x1080i] is selected for [RESOLUTION].
f Select [60Hz] or [50Hz] when anything other than [1920x1080p] or [1920x1080i] is selected for
[RESOLUTION].
10) Press the <ENTER> button.
f The conrmation screen is displayed.
11) Press qw to select [OK], and press the <ENTER> button.
Note
f The setting details are displayed in [RESOLUTION] and [VERTICAL SCAN FREQUENCY] of [EDID STATUS].
f The resolution and vertical scanning frequency settings may also be required on your computer or video device.
f After conguring settings, your computer or video device or the projector may be required to be turned off and on.
f A signal may not be output with the resolution and vertical scanning frequency that have been set, depending on your computer or video
device.
[HDMI IN]
Switch the setting when the external device is connected to the <HDMI IN> terminal of the projector and the
image is not projected correctly.
1) Press as to select [HDMI IN].
2) Press the <ENTER> button.
f The [HDMI IN] screen is displayed.
