Panasonic PT-DZ21K2

Chapter 4 Settings — [PROJECTOR SETUP] menu
128 - ENGLISH
Note
f The [LAMP RELAY] function is enabled when [SINGLE], [DUAL], [TRIPLE], or [QUAD] is selected in [LAMP SELECT].
f When [SINGLE] or [DUAL] is selected in [LAMP SELECT], lamps are switched at the specied time. When [TRIPLE] is selected in [LAMP
SELECT], lamps are switched three times every two hours after the specied time, and then the previous status is maintained until the next
specied time.
When [QUAD] is selected in [LAMP SELECT], three lamps light after the specied time, and three lamps to be lit are switched four times
every two hours. Eight hours after the specied time, four lamps light, and from the next specied time, three lamps are lit and switched
again.
f The operating time will be the local time. (x page 139)
[BRIGHTNESS CONTROL]
The projector is equipped with a luminance sensor to measure brightness and color of the lamp, and corrects
brightness and color of the projected image according to the changes in brightness and color of the lamp.
By using this function, it is possible to reduce the changes of brightness and color of the entire multiple screen, or
hold down the differences of the brightness and color, making it possible to maintain uniformity when constructing
multiple screen using multiple projectors.
Setting [BRIGHTNESS CONTROL GAIN]
Adjust the brightness when displaying multiple screens using multiple projectors.
1) Press as to select [BRIGHTNESS CONTROL].
2) Press the <ENTER> button.
f The [BRIGHTNESS CONTROL] screen is displayed.
3) Press as to select [BRIGHTNESS CONTROL GAIN].
4) Press qw to adjust.
Operation
Adjustment
Range of adjustment
Brightness
Maximum amount of
brightness correction
Press w.
The screen becomes brighter.
The maximum amount of
correction is reduced.
20 % - 100 %
Press q.
The screen becomes darker.
The maximum amount of
correction is increased.
Note
f When using only one projector, the value obtained by subtracting the value of the [BRIGHTNESS CONTROL GAIN] from 100 % is the
maximum amount of brightness correction. Brightness cannot be corrected through brightness control since the maximum amount of
correction becomes 0 % when [BRIGHTNESS CONTROL GAIN] is at 100 %.
f Brightness will be unsteady for eight minutes after a lamp is turned on. Adjust the brightness at least eight minutes after starting projection.
f The result of [BRIGHTNESS CONTROL GAIN] adjustments is reected on all image signals, internal test patterns, and on-screen menus.
f The [BRIGHTNESS CONTROL GAIN] setting is enabled even if [BRIGHTNESS CONTROL SETUP] is [OFF].
Setting [BRIGHTNESS CONTROL SETUP]
Set brightness control operation.
1) Press as to select [BRIGHTNESS CONTROL].
2) Press the <ENTER> button.
f The [BRIGHTNESS CONTROL] screen is displayed.
3) Press as to select [BRIGHTNESS CONTROL SETUP].
4) Press the <ENTER> button.
f The [BRIGHTNESS CONTROL SETUP] screen is displayed.
5) Press as to select [MODE].
6) Press qw to switch the item.
f The items will switch each time you press the button.
[OFF] Does not correct the brightness of the screen by the brightness sensor.
