Panasonic PT-RQ22KD

Chapter 4 Settings — [PROJECTOR SETUP] menu
ENGLISH - 185
1) Press as to select [REMOTE2 MODE].
2) Press qw to switch the item.
f The items will switch each time you press the button.
[DEFAULT]
Uses pin assignment of the <REMOTE 2 IN> terminal in standard setting. (x page 254)
[USER] Changes the setting of the <REMOTE 2 IN> terminal.
f When [USER] is selected, proceed to Step 3).
3) Press the <ENTER> button.
4) Press as to select one from [PIN2] to [PIN8], and press qw to switch the setting.
[FUNCTION BUTTON]
Set the function of the <FUNCTION> button on the remote control.
1) Press as to select [FUNCTION BUTTON].
2) Press the <ENTER> button.
f The [FUNCTION BUTTON] screen is displayed.
3) Press as to select a function.
[DISABLE] Disables the <FUNCTION> button.
[MULTI DISPLAY]
Switches the [MULTI DISPLAY MODE] setting. (x page 191)
[SUB MEMORY]
Displays the sub memory list. (x page 196)
[SYSTEM SELECTOR]
Switches the [SYSTEM SELECTOR] setting according to the input signal of the image being
projected.
f When the input is SDI1 to SDI4 equipped on this projector as the standard projector.
g The [DISPLAY OPTION] menu → [SDI IN] → [SINGLE LINK SETTING] → [SDI1]/[SDI2]/[SDI3]/
[SDI4] → [SYSTEM SELECTOR]
g The [DISPLAY OPTION] menu → [SDI IN] → [DUAL LINK SETTING] → [SDI1-2]/[SDI3-4] →
[SYSTEM SELECTOR]
g The [DISPLAY OPTION] menu → [SDI IN] → [QUAD LINK SETTING] → [SYSTEM SELECTOR]
f When the input is SDI1 to SDI4 on the Interface Board
g The [DISPLAY OPTION] menu → [SLOT IN] → [SINGLE LINK SETTING] → [SDI1 [SLOT1]]/
[SDI2 [SLOT1]]/[SDI3 [SLOT2]]/[SDI4 [SLOT2]] → [SYSTEM SELECTOR]
g The [DISPLAY OPTION] menu → [SLOT IN] → [DUAL LINK SETTING] → [SYSTEM
SELECTOR]
g The [DISPLAY OPTION] menu → [SLOT IN] → [QUAD LINK SETTING] → [SYSTEM
SELECTOR]
f When the input is anything other than SDI
The [PICTURE] menu → [SYSTEM SELECTOR]
[SYSTEM DAYLIGHT VIEW]
Switches the [SYSTEM DAYLIGHT VIEW] setting. (x page 103)
[FREEZE]
Temporarily pauses the image. (x page 154)
[WAVEFORM MONITOR]
Displays the waveform of the input signal. (x page 155)
[LENS MEMORY LOAD]
Loads the registered lens memory. (x page 160)
[PROJECTION METHOD]
Switches the [PROJECTION METHOD] setting. (x page 157)
4) Press the <ENTER> button.
[STATUS]
Display the status of the projector.
1) Press as to select [STATUS].
2) Press the <ENTER> button.
f The [STATUS] screen is displayed.
3) Press qw to switch the pages.
f The page will change each time you press the button.
[PROJECTOR TYPE] Displays the type of the projector.
