Chapter 7 Appendix — Technical information
ENGLISH - 257
f The IP address setting mode is canceled when the <ENTER> button is pressed, and the settings are
displayed in the self-diagnosis display in two second intervals as follows. Next display is an example when
[IP ADDRESS] is set to 192.168.0.10.
“192” “168” “000” “010”
Display end
Note
f The IP address setting mode is canceled when no setting operation is performed for 10 seconds or longer in the IP address setting mode.
f The IP address will be set to the following factory default setting when the <DEFAULT> button on the remote control is press while in the IP
address setting mode.
[DHCP] OFF
[IP ADDRESS] 192.168.0.8
Control device password
To initialize your password, consult your distributor.
Upgrade Kit
If the optional Upgrade Kit (Model No.: ET-UK20) is applied, the following functions are extended.
Function Standard status When the Upgrade Kit is applied
Adjustment range of
[VERTICAL KEYSTONE]
Maximum of ±40°
*1
Maximum of ±45°
*1
Adjustment range of
[HORIZONTAL KEYSTONE]
Maximum of ±15°
*1
Maximum of ±40°
*1
Adjustment range of
[CURVED CORRECTION]
Vertical arc, Maximum ±50
*1
Horizontal arc, Maximum ±50
*1
Vertical arc, Maximum ±100
*1
Horizontal arc, Maximum ±100
*1
Adjustment range of
[PINCUSHION]
Maximum of ±50
*1
Maximum of ±100
*1
[CUSTOM MASKING] Cannot be used. The image is masked in optional form.
[FLEXIBLE CORRECTION] of
[UNIFORMITY]
Correction value for brightness unevenness and
color unevenness cannot be set.
Correction value for brightness unevenness and
color unevenness can be set.
*1 The adjustment range of the menu. Refer to “[GEOMETRY] projection range” (x page 47) for the possible projection range.
