Panasonic PT-RQ22KD - Page 272

Chapter 7 Appendix — Technical information
272 - ENGLISH
Signal name
(SIGNAL FORMAT)
Resolution
(Dots)
Scanning freq.
Dot clock
freq.
(MHz)
4K
division
Format Color format Sampling
Horizontal
(kHz)
Vertical
(Hz)
4096 x 2160/24p
4 096 x 2 160 54.0 24.0
*1
297.0 SQ
3G-SDI Level-B
Dual Stream
YP
B
P
R
4:2:2 10bit
4 096 x 2 160 54.0 24.0
*1
297.0 IL
3G-SDI Level-B
Dual Stream
YP
B
P
R
4:2:2 10bit
4 096 x 2 160
*3
54.0 24.0
*1
297.0 SQ 6G-SDI Type 1 YP
B
P
R
4:2:2 12bit
4 096 x 2 160
*3
54.0 24.0
*1
297.0 IL 6G-SDI Type 1 YP
B
P
R
4:2:2 12bit
4 096 x 2 160
*3
54.0 24.0
*1
297.0 SQ 6G-SDI Type 1 YP
B
P
R
4:4:4 10bit
4 096 x 2 160
*3
54.0 24.0
*1
297.0 IL 6G-SDI Type 1 YP
B
P
R
4:4:4 10bit
4 096 x 2 160
*3
54.0 24.0
*1
297.0 SQ 6G-SDI Type 1 YP
B
P
R
4:4:4 12bit
4 096 x 2 160
*3
54.0 24.0
*1
297.0 IL 6G-SDI Type 1 YP
B
P
R
4:4:4 12bit
4 096 x 2 160
*3
54.0 24.0
*1
297.0 SQ 6G-SDI Type 1 RGB 4:4:4 10bit
4 096 x 2 160
*3
54.0 24.0
*1
297.0 IL 6G-SDI Type 1 RGB 4:4:4 10bit
4 096 x 2 160
*3
54.0 24.0
*1
297.0 SQ 6G-SDI Type 1 RGB 4:4:4 12bit
4 096 x 2 160
*3
54.0 24.0
*1
297.0 IL 6G-SDI Type 1 RGB 4:4:4 12bit
4096 x 2160/25p
4 096 x 2 160 56.3 25.0 297.0 SQ
3G-SDI Level-B
Dual Stream
YP
B
P
R
4:2:2 10bit
4 096 x 2 160 56.3 25.0 297.0 IL
3G-SDI Level-B
Dual Stream
YP
B
P
R
4:2:2 10bit
4 096 x 2 160
*3
56.3 25.0 297.0 SQ 6G-SDI Type 1 YP
B
P
R
4:2:2 12bit
4 096 x 2 160
*3
56.3 25.0 297.0 IL 6G-SDI Type 1 YP
B
P
R
4:2:2 12bit
4 096 x 2 160
*3
56.3 25.0 297.0 SQ 6G-SDI Type 1 YP
B
P
R
4:4:4 10bit
4 096 x 2 160
*3
56.3 25.0 297.0 IL 6G-SDI Type 1 YP
B
P
R
4:4:4 10bit
4 096 x 2 160
*3
56.3 25.0 297.0 SQ 6G-SDI Type 1 YP
B
P
R
4:4:4 12bit
4 096 x 2 160
*3
56.3 25.0 297.0 IL 6G-SDI Type 1 YP
B
P
R
4:4:4 12bit
4 096 x 2 160
*3
56.3 25.0 297.0 SQ 6G-SDI Type 1 RGB 4:4:4 10bit
4 096 x 2 160
*3
56.3 25.0 297.0 IL 6G-SDI Type 1 RGB 4:4:4 10bit
4 096 x 2 160
*3
56.3 25.0 297.0 SQ 6G-SDI Type 1 RGB 4:4:4 12bit
4 096 x 2 160
*3
56.3 25.0 297.0 IL 6G-SDI Type 1 RGB 4:4:4 12bit
4096 x 2160/30p
4 096 x 2 160 67.5 30.0
*1
297.0 SQ
3G-SDI Level-B
Dual Stream
YP
B
P
R
4:2:2 10bit
4 096 x 2 160 67.5 30.0
*1
297.0 IL
3G-SDI Level-B
Dual Stream
YP
B
P
R
4:2:2 10bit
4 096 x 2 160
*3
67.5 30.0
*1
297.0 SQ 6G-SDI Type 1 YP
B
P
R
4:2:2 12bit
4 096 x 2 160
*3
67.5 30.0
*1
297.0 IL 6G-SDI Type 1 YP
B
P
R
4:2:2 12bit
4 096 x 2 160
*3
67.5 30.0
*1
297.0 SQ 6G-SDI Type 1 YP
B
P
R
4:4:4 10bit
4 096 x 2 160
*3
67.5 30.0
*1
297.0 IL 6G-SDI Type 1 YP
B
P
R
4:4:4 10bit
4 096 x 2 160
*3
67.5 30.0
*1
297.0 SQ 6G-SDI Type 1 YP
B
P
R
4:4:4 12bit
4 096 x 2 160
*3
67.5 30.0
*1
297.0 IL 6G-SDI Type 1 YP
B
P
R
4:4:4 12bit
4
096 x 2 160
*3
67.5 30.0
*1
297.0 SQ 6G-SDI Type 1 RGB 4:4:4 10bit
4 096 x 2 160
*3
67.5 30.0
*1
297.0 IL 6G-SDI Type 1 RGB 4:4:4 10bit
4 096 x 2 160
*3
67.5 30.0
*1
297.0 SQ 6G-SDI Type 1 RGB 4:4:4 12bit
4 096 x 2 160
*3
67.5 30.0
*1
297.0 IL 6G-SDI Type 1 RGB 4:4:4 12bit
4096 x 2160/60p
4 096 x 2 160
*3
135.0 60.0
*1
594.0 SQ 6G-SDI Type 1 YP
B
P
R
4:2:2 10bit
4 096 x 2 160
*3
135.0 60.0
*1
594.0 IL 6G-SDI Type 1 YP
B
P
R
4:2:2 10bit
4096 x 2160/50p
4 096 x 2 160
*3
112.5 50.0 594.0 SQ 6G-SDI Type 1 YP
B
P
R
4:2:2 10bit
4 096 x 2 160
*3
112.5 50.0 594.0 IL 6G-SDI Type 1 YP
B
P
R
4:2:2 10bit
*1 The signal with 1/1.001x vertical scanning frequency is also supported.
*2 The optional 3G-SDI Terminal Board with Audio (Model No.: TY-TBN03G) is not supported.
*3 Only the combination of the <SDI 1 IN> terminal and the <SDI 3 IN> terminal of the optional Interface Board for 12G-SDI (Model No.:
ET-MDN12G10) is supported.
