1-3-3
11
1-3. Refrigerant Flow Diagram
Outdoor Unit: U-60PZ3E5
Ø12.7
Ø12.7 Ø15.88
Gas socket tube (Ø15.88-Ø12.7)
Liquid socket tube (Ø9.52-Ø6.35)
Ø6.35
Ø9.52Ø6.35
S-6071PU3E (60)
S-6071PF3E (60)
exchanger
Heat
Distributor
