Ref. No. Part No. Part Name & Description Remarks
L401 RLQZR73MT-T CHOKE COIL [M]
L503 RLQZ371 CHOKE COIL
[M]
L600 RLQB101JTD-D INDUCTOR [M]
L601 RLQB101JTD-D INDUCTOR [M]
L602 G0C100JA0030 INDUCTOR [M]
L603 G0C101JA0027 COIL [M]
L604 G0C3R3JA0027 COIL [M]
L702 G0ZZ00001930 CHOKE COIL [M]
L703 RLL500050T-Y RF CHOKE COIL [M]
L704 RLL500050T-Y RF CHOKE COIL [M]
L1301 7L1A62N BIAS OCS COIL [M]
L1302 RLQB470JTD-D RF CHOKE COIL [M]
T501 G4C6AEZ00001 MAIN TRANSFORMER
[M]
T502 RTP1H3E002 BACK-UP TRANSFORMER
[M]
COMPONENT COMBINATION
Z101 RLA2Z007-T COIL [M]
Z102 RLI2Z021M-T AM IF BLOCK [M]
Z120 ENV17290G1Y FM TUNER PACK [M]
Z501 ERZV10V511CS ZENER
[M]
Z601 B3RAB0000012 REMOTE SENSOR [M]
Z971 RGSD12A1445T RADA RESISTOR [M]
CERAMIC FILTERS
CF201 J0B1075A0086 CERAMIC CAPACITOR [M]
CF202 J0B1075A0077 CERAMIC FILTER [M]
RELAY
RL501 RSY0040M-0 POWER RELAY
[M]
OSCILLATORS
X102 RLFDFT22DD CRYSTAL OSCILLATOR [M]
X103 H0H720400005 CRYSTAL OSCILLATOR [M]
X300 H0H433400001 CRYSTAL OSCILLATOR [M]
X301 H2A100500006 RESONATOR [M]
X302 RSXD32K7S02 CRYSTAL OSCILLATOR [M]
X701 RSXC16M9S04 CRYSTAL OSCILLATOR [M]
DISPLAY TUBE
FL600 A2BC00000051 FL DISPLAY [M]
FUSES
F1 K5D801BK0007 800MA FUSE
[M]
FUSE HOLDERS
