Ref. No. Part No. Part Name & Description Remarks
FC1 EYF52BC FUSE HOLDER [M]
FC2 EYF52BC FUSE HOLDER [M]
FUSE PROTECTOR
FP501 K5G402AA0002 FUSE PROTECTOR
[M]
FP502 K5G102AA0002 FUSE PROTECTOR
[M]
HOLDERS
H303 K1YF08000003 8P WIRE HOLDER [M]
H307 RMR0320 11P WIRE HOLDER [M]
H309 RMR0318 9P WIRE HOLDER [M]
H503 K1YF06000002 6P WIRE HOLDER [M]
H601A RMR0313 CABLE HOLDER [M]
H601B RMR0313 CABLE HOLDER [M]
H604 RMR0321 12P WIRE HOLDER [M]
H605A RMR0316 7P WIRE HOLDER [M]
H605B RMR0316 7P WIRE HOLDER [M]
H606 RMR0316 7P WIRE HOLDER [M]
H608A RMR0312 3P CABLE HOLDER [M]
H608B RMR0312 3P CABLE HOLDER [M]
JACKS
JK101 RJH8304N JK ANTENNA [M]
JK300 GP1F32T JK OPTICAL TERMINAL [M]
JK301 K4BC04B00036 JK RED/BLACK SPEAKER [M]
JK302 K4BC04B00037 JK BLUE/GRAY SPEAKER [M]
JK303 RJH2213N-1 JK AUX IN [M]
JK501 K2AA2B000004 JK AC INLET
[M]
JK900 RJJ37TK07-X JK HEADPHONE [M]
EARTH TERMINAL
E501 SNE1004-2 EARTH TERMINAL [M]
E502 SNE1004-2 EARTH TERMINAL [M]
WIRES
W303 REXX0292 8P (POWER PCB-MAIN) [M]
W307 RWJ1111200XX 11P (MAIN-DECK) [M]
W308B RWJ0102095SS 2P DECK-CASS EJECT [M]
W309 RWJ1109290XX 9P WIRE (MAIN-DECK) [M]
W503 REXX0290 6P TRANS-PANEL [M]
W601 RWJ1104260XX 4P WIRE [M]
W604 REXX0294 12P (BTN-PANEL) [M]
W605 RWJ1107160XX 7P WIRE (H/P-PANEL) [M]
W606 RWJ0207130XX 7P (PANEL-TRANS) [M]
W1903 RWJ0102050KR MOTOR WIRE [M]
WH303 RJS1A5502 CABLE HOLDER [M]
