Panasonic SA-PM53E - Page 148

Ref. No. Part No. Part Name & Description Remarks
CN402 K1KB11A00020 11P CONNECTOR [M]
CN501 K1KA10AA0319 10P CONNECTOR [M]
CN501 K1MP09A00002 9P WIRE HOLDER [M]
CN601 K1MN21B00010 21P FFC CONNECTOR [M]
CN1305 K1MN21B00010 21P FFC CONNECTOR [M]
CN7001 K1MN16B00154 16P CONNECTOR [M]
CN7002 K1MN17B00032 17P CONNECTOR [M]
CP501 K1KA11AA0031 11P CONNECTOR [M]
CP502 K1KA06AA0031 6P CONNECTOR [M]
CP1301 K1MY05AA0043 5P CONNECTOR SOCKET [M]
CP1902 K1KA09BA0153 9P CONNECTOR [M]
CS971 RJU071H09M1 9P CONNECTOR [M]
COILS & TRANSFORMERS
L291 J0JBC0000019 CHIP INDUCTOR [M]
L292 J0JBC0000019 CHIP INDUCTOR [M]
L295 J0JBC0000019 CHIP INDUCTOR [M]
L301 G0A200D00002 RF CHOKE COIL [M]
L401 G0C3R3JA0027 COIL [M]
L501 G0B371HA0005 LINE FILTER
[M]
L503 G0AR76Y00003 CHOKE COIL [M]
L504 G0AR76Y00003 CHOKE COIL [M]
L601 G0C101JA0052 INDUCTOR [M]
L602 G0C101JA0052 INDUCTOR [M]
L603 G0C3R3JA0027 COIL [M]
L1301 G2ZZ00000024 BIAS OCS COIL [M]
L1302 G0C470JA0052 RF CHOKE COIL [M]
T501 G4CYAYY00077 POWER TRANSFORMER
[M]
T502 RTP1H3E002 SUB TRANSFORMER
[M]
COMPONENT COMBINATIONS
Z301 ENG07811QF TUNER PACK [M]
Z501 ERZVA5Z471 ZENER
[M]
Z601 B3RAB0000046 REMOCON SENSOR [M]
RELAY
RL501 K6B1ADA00011 RELAY
[M]
OSCILLATORS
X401 H2B100500004 CERAMIC RESONATOR [M]
X402 H0A327200111 CRYSTAL OSCILLATOR [M]
X461 H0H433400002 CRYSTAL OSCILLATOR [M]
X7201 H2B169500005 CRYSTAL OSCILLATOR [M]
DISPLAY TUBE
FL601 A2BB00000157 FL DISPLAY [M]
148
