9.21. Disassembly of CR16 Mechanism
- Follow the (Step 1) - (Step 6) of Item 9.4.
- Follow the (Step 1) - (Step 2) of Item 9.5.
- Follow the (Step 1) - (Step 4) of Item 9.7.
- Follow the (Step 1) - (Step 5) of Item 9.14.
9.22. Replacement of optical pickup unit (CD mechanism)
- Follow the (Step 1) - (Step 6) of Item 9.4.
- Follow the (Step 1) - (Step 2) of Item 9.5.
- Follow the (Step 1) - (Step 4) of Item 9.7.
- Follow the (Step 1) - (Step 5) of Item 9.14.
