Mode Present After modify Description
F27 NAOU Normal all open up
NAOD Normal all open down
NACU Normal all close up
NACD Normal all close down
F28 NACL Normal all close
F29 NAOP Normal all open
All open / close during
play
F27 PAOU Play all open up
PAOD Play all open down
PACU Play all close up
PACD Play all close down
F28 PACL Play all close
F29 PAOP Play all open
Lock for shipment F27 LOCK Lock
Total 5 37
- In CR16 Self Diagnostic mode, the errors that occurred in CR16
Mechanism can be recalled and displayed, in the order of the
occurrence.
- Only the first 5 errors will be memorized. There after the subsequence
error shall be ignored and not memorize.
- The error codes shall be memorized in backup memory. For system with
EEPROM as memory backup, memory space in EEPROM is necessary.
- User Operation:
1. To enter CR16 Self Diagnostic mode
In Self Diagnostic Mode, press [CD CHECK]. System will enter "CR16
Self Diagnostic mode" and shows the content of 1
st
error code.
2. To display all error code memorized
In "CR16 Self Diagnostic mode", press [CD CHECK] to display
subsequence error code. It shall repeat after reaching error no. 5.
27
