Panasonic SC-HT855 User Manual

RQT8724
12
Simple Setup
∫ Television with an S-VIDEO IN terminal
The S-VIDEO OUT terminal achieves a more vivid picture than the VIDEO OUT terminal by separating the
chrominance (C) and luminance (Y) signals. (Actual results depend on the television.)
Connecting to a television with AUDIO/VIDEO terminals
Using other video connections for improved picture quality
P B
P R
Y
COMPONENT VIDEO OUT
S-VIDEO
S-VIDEO
OUT
OUT
AV OUT
OPTICAL IN
AV
r
s
R
L
TV
TV
AUDIO
AUDIO
IN
IN
AUX
AUX
VIDEO
VIDEO
OUT
OUT
AUDIO
OUT
L
R
VIDEO IN
AUDIO
IN
VIDEO OUT
Television
(not included)
Back of this unit
Video cable
(not included)
Audio cable
§
(not included)
§
This audio connection will enable you to play audio from your television through your home theater system.
Refer to “Operating other equipment” (➜ page 39).
You can also connect to the AUX terminals on this unit. The TV AUDIO IN and AUX terminals are for external
audio input.
P B
P R
Y
R
L
TV
TV
AUDIO
AUDIO
IN
IN
AUX
AUX
COMPONENT VIDEO OUT
VIDEO
VIDEO
OUT
OUT
AV OUT
OPTICAL IN
AV
r
s
S-VIDEO
S-VIDEO
OUT
OUT
AUDIO
IN
S-VIDEO
IN
AUDIO
OUT
L
R
VIDEO OUT
Television
(not included)
S-video cable
(not included)
Back of this unit
Audio cable
§
(not included)
§
This audio connection will enable you to play audio from your television through your home theater system.
Refer to “Operating other equipment” (➜ page 39).
You can also connect to the AUX terminals on this unit. The TV AUDIO IN and AUX terminals are for external
audio input.
Audio, video and radio connections
8606En_p06-19.f m Page 12 Wednesday, March 15, 2006 4:05 PM
