The error code is automatically display after entering into self-diagnostic mode.
Error Code Diagnosis Contents Description of error Automatic FL Display Remarks
H01 Mode SW, plunger
an
d capstan motor
abnorma
l
For deck mechanism unit (For deck 1/2).
Pres
s [
] on main unit for
nex
t error.
H02 Rec INH SW
abnorma
l
For deck mechanism unit (For deck 2).
Pres
s [ ] on main unit for
nex
t error.
H03 HALF SW abnormal For deck mechanism unit (For deck 1/2).
Pres
s [
] on main unit for
nex
t error.
F01
F02
Reel pulse abnormal
TP
S error
For deck mechanism unit (For deck 1/2).
Pres
s [
] on main unit for
nex
t error.
F15 RESET SW
abnorma
l
REST SW: ON is not
detecte
d within the
specifie
d time.
For CD unit (For Traverse).
Pres
s [
] on main unit for
nex
t error.
F26 Transmission error
between CD Servo
LS
I IC and
mi
croprocessor IC
When set to CD mode,
the sense signal does
no
t turn “Low”, a fail safe
tim
e after system
comman
d transmission
is sent.
For CD unit (For Traverse).
Press [
] on main unit for
next error.
F61 Power Amp IC output
abnorma
l
Upon power on,
PCONT=
HIGH,
DCDET=
L after checking
LSI.
For power.
Pres
s [ ] on main unit for
nex
t error.
IHMS Cam gear
abnormality
Cam gear does not
rotat
e to “HOME”
position
.
For CD changer unit (CRS1).
Pres
s [SINGLE CHANGE] on main unit
fo
r next error.
ICSL Cam gear/gear units
abnorma
l
Cam gear does not
rotat
e to “PLAY” driving
positio
n and hence does
no
t drive playing tray to
“STOCK
” position.
For CD changer unit (CRS1).
Pres
s [SINGLE CHANGE] on main unit
fo
r next error.
ISTK Drive rack/gear
assembl
y abnormal
The tray drive rack does
no
t move to “STOCK”
position
. (Tray does not
move to “STOCK”
po
sition)
For CD changer unit (CRS1).
Pres
s [SINGLE CHANGE] on main unit
fo
r next error.
IPLY Drive rack/gear
assembl
y abnormal
The tray drive rack does
no
t move to “PLAY”
position
. (Tray does not
mov
e to “PLAY” position)
For CD changer unit (CRS1).
Pres
s [SINGLE CHANGE] on main unit
fo
r next error.
