Panasonic SC-TM760 - Page 18

Error Code Diagnosis Contents Description of error Automatic FL Display Remarks
ITOP UD assembly UD Rack does not move
to front direction. This
lea
d to UD base not
rais
e to top position.
For CD changer unit (CRS1).
Pres
s [SINGLE CHANGE] on main unit
fo
r next error.
IUDS UD assembly After TOP SW is
detected
, UD rack does
no
t move into tray 1
position
.
For CD changer unit (CRS1).
Pres
s [SINGLE CHANGE] on main unit
fo
r next error.
HOME Cam gear/gear
assembl
y abnormal
Cam gear does not
mov
e to “HOME”
posi
tion under following
condition
s
1. After tray is load to
“PLAY
” position.
2. After tray is unload
to “STOCK” position.
For CD changer unit (CRS1).
Pres
s [SINGLE CHANGE] on main unit
fo
r next error.
LOAD Tray drive assembly
abnorma
l
Tray unit does not move
fro
m “STOCK” to “PLAY”
positio
n
For CD changer unit (CRS1).
Pres
s [SINGLE CHANGE] on main unit
fo
r next error.
PDRV Cam gear/gear
assembl
y abnormal
Cam gear does not
mov
e from “HOME” to
“PLAY
” drive position.
For CD changer unit (CRS1).
Pres
s [SINGLE CHANGE] on main unit
fo
r next error.
UDU UD base asssembly
abnorma
l
UD Base assembly does
no
t move upwards from
tra
y 5 to tray 2
For CD changer unit (CRS1).
Pres
s [SINGLE CHANGE] on main unit
fo
r next error.
UDD UD base asssembly
abnorma
l
UD Base assembly does
no
t move downwards
fro
m tray 1 to tray 5.
For CD changer unit (CRS1).
Pres
s [SINGLE CHANGE] on main unit
fo
r next error.
UD1 UD base asssembly
abnorma
l
UD Base assembly does
no
t move to tray 1.
For CD changer unit (CRS1).
Pres
s [SINGLE CHANGE] on main unit
fo
r next error.
F1NG Fail - safe mode. (For
open/clos
e tray
unit(s))
When the tray open
opera
tion is performed, it
fails to open. It will
automatic
ally close all
trays after the time-out
by the microprocessor.
Durin
g this time when it
fails
, the error code will
appear
.
For CD changer unit (CRS1).
Pres
s [SINGLE CHANGE] on main unit
fo
r next error.
F2NG Fail - safe mode. (For
open/clos
e tray
unit(s))
When the tray close
opera
tion is performed, it
fail
s to close. It will
automatic
ally open all
trays after the time-out
by the microprocessor.
Durin
g this time when it
fails
, the error code will
appear
.
For CD changer unit (CRS1).
Pres
s [SINGLE CHANGE] on main unit
fo
r next error.
18
service manual SC-TM760
