15
VQT1P61
Before using
This is a hole for attaching the unit to the
optional tripod.
(Please carefully read the operating
instructions for how to attach the unit to
the tripod.)
≥
When the tripod is used, the card/battery
door cannot be opened. Insert an SD
card and the battery before attaching this
unit to the tripod. (
l
19, 27)
You can record the image while viewing
it on the LCD monitor.
1 Place your finger on the LCD
monitor open part A and pull
the LCD monitor out in the
direction of the arrow.
≥ It can open up to 90o.
2 Adjust the angle of the LCD
monitor as desired.
≥ It can rotate up to 90o A towards
the lens or 90o B towards the
opposite direction.
≥ The brightness and colour level of the
LCD monitor can be adjusted from the
menu. (l 37)
≥
The unit may be damaged or fail if the
LCD monitor is forcibly opened or rotated.
Attaching to a tripod Using the LCD monitor
A
A
B
