70
VQT1P61
With other products
With other products
With a TV
The motion pictures and still pictures
recorded by this unit can be played back
on a TV.
≥ Use the AC adaptor to free you from
worrying about the battery running
down.
1 Slide the terminal cover lock
to OPEN and then open the
terminal cover.
2 Connect this unit to the TV.
A AV cable (supplied)
≥ Insert the plugs as far as they will
go.
≥ Do not use any other AV cables
except the supplied one.
≥ If your TV is not equipped with AV
Input Sockets, the 21-pin Adaptor
B (optional) is necessary. Consult
your dealer.
3 Rotate the mode dial to select
or .
4 Change the input channel on
the TV.
≥ The channel set will differ
depending on the terminal to which
the unit is connected.
5 Start playback on this unit.
The image and audio are output on
the TV.
Playback on TV
VIDEO IN
AUDIO IN
A
B
