Panasonic SDR-S9 - Charging Time and Recordable Time

Setup
23
VQT1P61
The times shown in the tables below are for when the temperature is 25 oC and the
humidity is 60%. If the temperature is higher or lower than 25 oC, the charging time will
become longer.
∫ Charging time
≥ The charging time shown in the table are approximations.
≥ “2 h 10 min” indicates 2 hour 10 minutes.
∫ Recordable time
≥ The actual recordable time refers to the recordable time when repeatedly starting/
stopping recording, turning the unit on/off, press the zoom button, etc.
≥ The recordable time shown in the table are approximations.
≥ “1 h 10 min” indicates 1 hour 10 minutes.
≥ The display changes as the battery capacity reduces.
####.
If the battery discharges, then ( ) will flash.
≥ The recordable times will vary depending on the status of use. These times are
approximations. The recordable time will become shorter when you use this unit with
the LCD monitor lit up with the [POWER LCD] setting on.
≥ The batteries heat up after use or charging. This unit will also heat up while being
used. This is not a malfunction.
≥ Be aware that the operating time of the battery will become shorter in low
temperatures. We recommend charging a spare battery for use when recording.
Charging time and recordable time
Battery model number Voltage/capacity Charging time
Supplied battery/
VW-VBJ10 (optional)
3.6 V/1000 mAh 2 h 10 min
Battery model
number
Voltage/
capacity
Maximum
continuously
recordable time
Actual recordable
time
Supplied battery/
VW-VBJ10
(optional)
3.6 V/
1000 mAh
1 h 10 min 40 min
