Panasonic TH-42PY80P - Page 87

87
TH-42PY80P, PZ80B/E
A-BOARD PARTS LOCATION
TH-42PY80P, PZ80B/E
A-BOARD PARTS LOCATION
Parts Location
A-BOARD (FOIL SIDE)
IC2008 H-4
IC2107 H-4
IC2109 G-5
IC2110 G-5
IC2401 G-4
IC2403 G-5
IC3001 H-2
IC4511 D-3
IC4512 D-2
IC4513 E-3
IC4517 E-2
IC4801 F-4
IC5400 F-5
IC5401 G-5
IC5600 B-3
IC5601 B-4
IC8004 D-4
IC8301 H-4
IC8302 H-4
IC8401 A-5
IC8404 B-4
IC8405 B-5
IC8408 B-5
IC8409 B-5
ICIC
Q1100 F-4
Q2001 I-5
Q2002 H-5
Q2022 H-4
Q2028 G-5
Q2029 G-5
Q2030 G-5
Q2032 I-6
Q2033 G-5
Q4500 D-2
Q4502 D-1
Q4503 E-1
Q4504 E-2
Q4505 E-2
Q4520 D-2
Q4521 D-2
Q4522 E-2
Q4523 D-2
Q4831 G-4
Q4832 G-4
Q4833 F-4
Q4834 F-5
Q4835 F-5
Q4836 F-5
Q5522 F-4
Q5562 G-4
Q5690 D-2
Q5691 B-1
Q5693 B-1
TRANSISTOR
TP0190 C-2
TP0191 E-5
TP0192 C-2
TP0193 C-2
TP0194 C-2
TP1043 C-3
TP1102 F-4
TP1103 E-4
TP1104 G-4
TP1105 G-4
TP1107 G-4
TP2008 H-3
TP2009 H-4
TP2010 I-4
TP2012 I-4
TP2014 I-4
TP2017 I-4
TP2030 H-5
TP2031 I-5
TP2032 I-5
TP3000 H-1
TP3001 G-1
TP3002 G-1
TP3003 H-1
TP3004 I-3
TP3005 I-3
TP3006 H-3
TP3007 I-3
TP3008 E-3
TP3009 E-3
TP3013 I-2
TP3014 F-3
TP3015 H-3
TP3017 H-1
TP3018 H-1
TP3019 H-1
TP3020 G-1
TP3021 I-3
TP4200 F-6
TP4201 F-6
TP4202 E-6
TP4203 E-6
TP4204 E-6
TEST POINT
Parts Location
A-BOARD (COMPONENT SIDE)
IC2108 A-6
IC2012 B-3
IC2013 B-3
IC2106 B-3
IC2301 B-4
IC2010 C-4
IC1100 D-4
IC1103 D-4
IC5404 D-5
IC1101 E-4
IC5405 E-4
IC8601 E-4
IC4200 E-5
IC4203 E-5
IC4510 F-2
IC4514 F-2
IC4515 F-2
IC8001 F-3
IC8002 F-4
IC4800 G-1
IC8554 G-2
IC5660 G-4
IC8003 G-4
IC8403 H-5
IC
Q2027 D-5
Q3000 A-1
Q3001 A-1
Q3002 C-1
Q3003 C-1
Q3004 C-1
Q3005 C-1
Q3009 B-3
Q3010 B-3
Q4501 E-2
Q4514 E-3
Q4515 E-3
Q4516 E-3
Q4517 E-3
Q4518 E-2
Q4519 E-3
Q5561 C-4
Q5600 H-3
Q5601 H-3
Q5602 H-4
Q5606 H-4
Q5607 H-4
Q5692 G-2
Q8401 H-5
Q8402 H-5
Q8801 H-1
Q8802 H-1
Q8850 F-2
Q8851 F-2
Q8852 F-2
Q8853 F-2
TRANSISTOR
TP1042 G-3
TP4840 H-1
TEST POINT
TP4205 E-6
TP4206 E-6
TP4207 E-6
TP4208 E-6
TP4209 E-6
TP4210 E-6
TP4211 E-6
TP4212 E-6
TP4213 E-6
TP4214 E-6
TP4215 E-6
TP4216 E-6
TP4217 E-6
TP4218 E-6
TP4219 E-6
TP4220 E-6
TP4221 E-6
TP4222 E-6
TP4223 E-6
TP4500 D-1
TP4501 E-1
TP4502 D-1
TP4503 E-1
TP4504 D-2
TP4505 E-2
TP4512 E-3
TP4821 A-2
TP4822 A-2
TP4825 A-2
TP4826 A-2
TP4827 A-2
TP4828 A-2
TP4829 B-2
TP4830 B-2
TP4831 B-2
TP4832 B-2
TP4835 B-2
TP4837 A-1
TP5400 F-6
TP5600 B-3
TP5601 B-4
TP5602 B-3
TP5603 F-1
TP5604 F-1
TP5605 F-1
TP5606 F-1
TP5607 F-1
TP5608 F-1
TP5660 D-4
TP5700 G-4
TP5701 H-3
TP5702 A-2
TP5705 G-4
TP5706 G-4
TP8037 D-4
TP8301 H-5
TP8401 B-5
TP8402 A-5
TP8403 B-5
TP8404 B-5
TP8501 D-3
TP8745 C-2
TP8801 B-1
TP8802 B-1
TP8803 B-1
TP8804 B-1
TP8805 B-1
TP8806 B-1
TP8807 B-1
TP8808 B-1
TP8851 E-4
TPC0F F-4
TPEC0 H-6
TPM0N D-2
TPMH12 E-4
TPMH33 F-5
TPS0N H-6
TPS0S F-4
TPS15V H-6
TPST5 H-6
A
