Panasonic th-50ph10uk - 16 Mechanical Replacement Parts List

Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
1 EUR7636070R REMOTE CONTROLER 1
K1YD80000002 80P CONNECTOR 1
2 K2CG3YY00023 AC CORD(U/L) 1
3 L6FAYYYH0050 FAN UNIT(80MM MMMC) 2
4 MD50H10A1J PLASMA DISPLAY PANEL 1
5 TBMA227 PANASONIC BADGE 1 PAVCA
6 TBXA46601 POWER BUTTON 1
7 TBXA46701A 5KEY BUTTON 1
8 TESD031 SPRING 1
9 TKGA5357S FRONT GLASS 1 PAVCA
10 TKKC5213 LED PANEL 1
11 TKKC5276 REMOTE SENSOR PANEL 1 PAVCA
12 TKKL5266 COVER 1
13 TKRA20501 HANDLE 2
14 TMKG558 SPONGE(TKG/UPPER/BOT
TOM)
2
15 TMKG559 SPONGE(TKG/LEFT/RIGH
T)
2
16 TMKG669 FAN SPONGE 2
TMM15414-2 CLAMPER 1
TMM16473-1 CLAMPER 1
TMM17434-2 CLAMPER 1
TMM17499 CLAMPER 1
TMM25401 CLAMPER 2
TMM6463-1 CLAMPER 1
TMM7464-2 CLAMPER 3
TMM7468-1 CLAMPER 3
TMME047 CLAMPER 3
TMME061 CLAMPER 4
TMME185 CLAMPER 2
TMME190 CLAMPER 1
17 TMME203 CLAMPER 2
TMME217 CLAMPER 1
TMME228 CLAMPER 2
TMME260 CLAMPER 4
TMME261 CLAMPER 1
18 TMMJ068 RUBBER(FAN) 6
19 TMMX128 SW_ATTATCHMENT 1
20 TMMX141 M8 SPACER 4
21 TMMX181 AC CODE CLAMPER A 1 PAVCA
TMWC015 POWER BUTTON BRACKET 1
TPD169487 JOINT 4
22 TQB2AA0802 INSTRUCTION
BOOK(ENG/FRE/SPA)
1 PAVCA
23 TSXL519 CABLE(C10-C20) 1
24 TSXL554 CABLE(C22-C32) 1
25 TSXL562 CABLE(D31-C11) 1
26 TSXL584 CABLE(DS1-DN1) 1
27 TSXL600 CABLE(D32-C21) 1
28 TSXL604 CABLE ASSY(SC20-D20) 1 PAVCA
29 TXAUX02XETUO AC INLET ASSY 1 PAVCA
30 TXFKU14RSER REAR COVER 1 PAVCA
31 TXFKY09RSER CABINET ASSY 1 PAVCA
32 TXFMZ010XET STAND BLOCK ASSY 2 PAVCA
TXJSPL0XET SPEAKER LEAD(DS8-
H37)
1 PAVCA
TXJSPR0XET SPEAKER LEAD(DS7-
H37)
1 PAVCA
UR76EC2803AA BATTERY COVER 1
THEA068N SCREW 4
THEL0239 SCREW 12
THEL027N SCREW 8
THEL037N SCREW 1
THEL0429 SCREW 10
THTD013N SCREW 6
THTD0179 STEP SCREW(P-SPACER) 3
THTF011N SCREW 96
XTB4+10JFJ SCREW(VESA
BRACKET)ROHS
22
XTV3+10GFJ SCREW 3
XTV3+10JFJ SCREW 5
XTV3+8JFJ SCREW 6
Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
XYN3+F10FJ SCREW 1
XYN3+F8FJ SCREW 16
XYN3+J12FJ SCREW 42
XYN3+J8FJ SCREW 10
XYN4+E8FJ SCREW 1
XYN4+F10FJ SCREW 6
XYN4+F10FJK SCREW 7
XYN4+F30FJK SCREW (BC TOP6
SIDE6: AL)
12
XYN5+C20FJ SCREW 8
XYN8+F20FJK SCREW 4
16 Mechanical Replacement Parts List
119
TH-50PH10UK
