Preface
The Digital Disk Recorder WJ-RT416 is designed for use within a surveillance system. The digital disk recorder is a
recording device using a hard disk drive to record pictures of surveillance cameras instead of using videotapes so
that pictures recorded by repeated overwriting will not experience deterioration of the recorded picture quality.
Up to 16 cameras can be connected directly with this unit and it is possible to record images from them. It is also
possible to display images from multiple cameras (multi-screen), to display images from a camera to camera
sequentially (sequential display), and to operate the connected cameras using the recorder.
Configuration of the settings of the recorder can be made using the monitoring software, and operation of the
recorder can be made using the monitoring software and a web browser.
The following models are described as "WJ-RT416" in these operating instructions.
• WJ-RT416K: No built-in HDD is provided
• WJ-RT416: Built-in HDD x1
• WJ-RT416VK: Built-in DVD drive x1, no built-in HDD is provided
• WJ-RT416V: Built-in DVD drive x1, built-in HDD x1
Monitoring software
The monitoring software consists of the following.
RT4Client
The principal functions of the monitoring software can be operated using the RT4Client. To use the monitoring soft-
ware, start the RT4Client first.
The following are the functions of the RT4Client.
• Displaying of live images from the cameras (normal display, frame display, sequential display)
• Control of the cameras (setup, operation)
• Playback of recorded images on the recorder
• Configuration of the settings of the recorder
• Operation of the recorder
• Reception of an event occurrence notification from the recorder and displaying of images recorded by the alarm
recording
• Download of recorded images on the recorder
• Download of data from the recorder (log, language file, setup data, etc.)
• Upload of data to the recorder (language file, firmware, setup data, etc.)
• Remote talk
RT4Viewer
Recorded images downloaded on the HDD of the PC can be played using the RT4Viewer. The RT4Viewer can start
using the interface of the RT4Client.
The functions of the RT4Viewer:
• Playback of downloaded recorded images
• Alteration check of data
• File conversion to Windows Media format
Web browser
The following are available functions using a web browser.
• Displaying live images from the cameras
• Control of the cameras (panning/tilting, zooming, focusing, moving the camera to the preset position, etc.)
• Playback of recorded images on the recorder
• Download of recorded images on the recorder
