Screenshot 2

The pop-up menu will be displayed.

Step 3

Select "Disconnect".

→ The connection with the selected camera will be dis-

connected.

Note:

When "Disconnect on All Areas" is selected, all cam-

eras from which the currently displayed images

(live/playback) will be disconnected.
