Using a one-gang junction box
• Secure the mount bracket (accessory) to the one-gang junction box built in a ceiling or a wall.
Note:
• Ceiling installation:
The mount bracket shall be mounted with aligning the front side (the lens side) of the camera
with the position of the arrow in "h".
• Wall installation:
The mount bracket shall be mounted with "h" facing upward.
83.5 mm {3-9/32"}
One-gang junction box
Mount bracket (accessory)
