25
Connection example
<Required cable>
LAN cable (category 5 or better, straight)
Important:
• Use a switching hub which is compliant with 10BASE-T/100BASE-TX.
• When connecting WV-SW155M cameras, use a PoE hub with M12 connectors.
PoE device (hub)
PC
LAN cable
(category 5 or better, straight)
LAN cable
(category 5 or better, straight)
LAN cable
(category 5 or better, straight)
