5 Configuration (continuous)
5.2 Peripherals
5.2.1 Cutting torch
Spec number
Rated
current
Shape
Cooling
method
Rated
duty cycle
Cable
length
Apply
machine
YT-06PD3HAE 60A Angle Air cooling 100% 10m YP-060PF
YT-06PE3HAE 60A Pen Air cooling 100% 10m YP-060PF
YT-06PD3HAF 60A Angle Air cooling 100% 20m YP-060PF
YT-06PE3HAF 60A Pen Air cooling 100% 20m YP-060PF
YT-06PD3HAG 60A Angle Air cooling 100% 30m YP-060PF
YT-06PE3HAG 60A Pen Air cooling 100% 30m YP-060PF
YT-10PD3HAE 100A Angle Air cooling 60% 10m YP-100PF
YT-10PE3HAE 100A Pen Air cooling 60% 10m YP-100PF
YT-10PD3HAF 100A Angle Air cooling 60% 20m YP-100PF
YT-10PE3HAF 100A Pen Air cooling 60% 20m YP-100PF
YT-10PD3HAG 100A Angle Air cooling 60% 30m YP-100PF
YT-10PE3HAG 100A Pen Air cooling 60% 30m YP-100PF
5.2.2 Cutting tip·electrode
Cutting tip · electrode have long cutting tip、long electrode and short cutting tip、short electrode two types.
·Short cutting tip· short electrode
Cutting for thin plate cutting
Model
number
Cutting tip Electrode Protective cap
YT-06PD/PE3
TET01110
(40A)
TET01310
(60A)
TSM06626
(100A)
TET02033
TGN00147
YT-10PD/PE3
·Long cutting tip · long electrode
Cutting for angle form, concave work piece (base metal)
Model
number
Cutting tip Electrode Protective cap
YT-06PD/PE3
TET01114
(40A)
TET01313
(60A)
TET02040
TGN00147
YT-10PD/PE3
When gouging, please use the specialized cutting tip for gouging
·Cutting tip for gouging · electrode
Model
number
Cutting tip for
gouging
Electrode Protective cap
YT-06PD/PE3
TET02502
(60A/100A)
TET02033 TGN00147
YT-10PD/PE3
