Panasonic YP-100PF - Plasma

67
16 Table to adjust output current regulation and plasma
Output current
Cutting torch
cable length
Over air pressure Low air pressure
35A
10m 0.49MPa 0.34MPa
20m 0.52MPa 0.37MPa
30m 0.54MPa 0.39MPa
60A
10m 0.59MPa 0.39MPa
20m 0.62MPa 0.42MPa
30m 0.64MPa 0.44MPa
80A
10m 0.59MPa 0.39MPa
20m 0.62MPa 0.42MPa
30m 0.64MPa 0.44MPa
100A
10m 0.59MPa 0.39MPa
20m 0.62MPa 0.42MPa
30m
0.64MPa
0.44MPa
