6 Names and Functions (continuous)
The dial ③
The rotary knob can provide the function of potentiometer (The setting of current and time etc.). For
example, in order to set cutting current as 30A, please rotate right (increase) or left (decrease) until
displayed value (digital display window) reaches 30A.
Confirm (④ air check) button
·On stand-by status, it can be used as air check button.
On stand-by status, the button is pressed. After releasing, air valve is kept ON for 60s, and then air valve
turns off. (Even if the button is pressed for a while, the result is same.).
· When the cutting navigation LED is lit, it can be used as the button confirming on cutting navigation
condition.
·When submenu is lit, it can be used as the button confirming on the settings of the submenu.
⑤ Air check display LED
During air check, it is lit
Selection button ⑥
Selection of the cutting navigation, detailed item. The LED of corresponding item is lit.⑪
· cutting navigation:
By selecting material, thickness and cutting method (manual cutting, automatic cutting) base metal, the
cutting condition can be displayed.
For details, please refer to 【8.4 cutting navigation 】.
⑦ The functional status display LED
The setting functional status by means of submenu can be displayed
·「 self-hold 」LED: When self-hold 「on」, it is lit by means of submenu setting.
·「the cutting torch monitoring」LED:
When the cutting torch monitoring「on」, it is lit by means of submenu setting.
After setting the cutting torch monitoring 「on」, when the remaining the cutting torch monitoring number
of times or duration is 0, it blinks.
·「 gouging 」LED: When gouging mode is selected, it is lit by means of submenu setting.
·「 function 」LED: The cutting machine is not used.
Cutting navigation material selection item ⑧
It is used to select cutting material by means of cutting navigation. For details, please refer to 【8.4
cutting navigation 】.
Operation lock display LED⑨
When the setting operation is locked, it is lit by means of submenu setting.
⑩The recommended range of air pressure display LED
During cutting or air checking, it is lit when air pressure is within the recommended range.
Item display LED⑪
·「 cutting navigation 」LED: When the cutting navigation is selected, it is lit.
·「 submenu 」LED: When submenu is selected, it is lit.
·「OP」 LED: For the cutting machine, it is not used. (The selectable item can’t be selected.)
⑫The adjusting knob for air pressure
· When air pressure is adjusted, it can be used
Setting pressure: 0.49mpa (before shipment)
The recommended pressure for every length of the cutting torches
The cutting
torch rated
current
The cutting torch cable length
10m(before
shipment)
20m 30m
35A 0.39mpa(4.0kgf/cm
2
) 0.42mpa(4.3kgf/cm
2
) 0.44mpa(4.5kgf/cm
2
)
60A 0.49mpa(5.0kgf/cm
2
) 0.52mpa(5.3kgf/cm
2
) 0.54mpa(5.5kgf/cm
2
)
80A 0.49mpa(5.0kgf/cm
2
) 0.52mpa(5.3kgf/cm
2
) 0.54mpa(5.5kgf/cm
2
)
100A 0.49mpa(5.0kgf/cm
2
) 0.52mpa(5.3kgf/cm
2
) 0.54mpa(5.5kgf/cm
2
)
·The adjustment method for air pressure
(1) On stand-by status, please press the DECIDE button
(2) Pull the air pressure adjusting knob out
(3) Rotate air pressure adjusting knob to adjust
(4) Press air pressure adjusting knob to lock
(5) Press the DECIDE button to end the air check.
