USER MANUALSECURITY-SERVICE SYSTEM PANDORA CAMPER
EN
System modules layout
Base unit
Blocking relay (circuit
being blocked)
External VALET button
Sensor DMS-100 BT
1
2
3
4
5
6
7
8
9
10
Base unit of the system
Built-in GSM modem (GPRS/SMS/LBS-services)
A built in modem allows the system to work in a mobile network using an installed SIM card: voice
and SMS notifications, control from a phone using DTMF-commands, determination of coordinates
based on cellular base station location (only for 500* command), connection with our online-service
and mobile applications.
For the correct operation of the GSM functions, an owner should monitor the status/balance of the
SIM card installed in the system. If the SIM card is blocked or defective, GSM functions of the system will
be unavailable.
Built-in GPS/GLONASS-receiver
A built-in GPS/GLONASS-receiver is designed to determine current location and to automatically
determine date and time.
!
To auTomaTically deTermine daTa and Time, iT is required To seT correcT uTc Time zone using The mobile app or The
online-service.
2.4GHz radio channel, Bluetooth 5.0 protocol (BT5.0)
An integrated radio channel is used to connect the system with a mobile phone and additional
Bluetooth devices. The system supports up to 14 additional Bluetooth devices: 1 remote control D-030,
up to 3 radio tags, 1 mobile phone, up to 10 DMS-100BT sensors, up to 2 radio relays BTR-101, 1 RHM-
03BT module, 1 BT-01 relay or DI-04 module.
Digital protection AES (128 Bit)
Dialog coding of commands with a 128-bit encryption key guarantee secure communication via
the radio channel. The encryption key can be changed when you re-pair a remote control or additional
Bluetooth devices.
3D-accelerometer
A built-in accelerometer is used to detect shock/motion/tilt:
• 2 zones of the shock sensor (alarm/warning);
• Separate sensitivity adjustment by zones;
• Engine blocking on motion start;
• Central lock closing when start driving.
