USER MANUAL
PANDORA MINI V3 CAR SERVICE-SECURITY SYSTEM
nects to an appropriate CAN-High wire of a car..
Wire 12 (Yellow-black) 200mA (-) CH5/CAN2-L — wire of digital bus CAN2-
Low. It connects to an appropriate CAN2-High wire of a car. This channel can be
assigned as an output, it will not work as a digital bus in this case.
Wire 13 (Blue-black) 200mA (-) CH7 — Factory setting is “Turn lights”. This
wire connects to a hazard flashers button of a car.
Wire 14 (Yellow) (+) INP2 — Factory setting is ”Ignition” input, it is a guard-
ed and controlled zone. This wire connects to an appropriate wire where 12V
voltage appears when ignition is switched on. If there is no ignition status in a
CAN-bus, this input must be connected.
Wire 15 (Purple) 2 (+) CH8 — Factory setting is “Siren”. It connects to a
siren control wire (+).
Wire 16 (Red) (+) — power supply of the system “+12V”. It must be con-
nected to a reliable conductor with constant voltage of 12V.
SYSTEM CONFIGURATION AND PROGRAMMING
System settings and parameters can be configured using the Pandora
Alarm Studio or Pandora Specialist application. Some functions can be con-
figured only by the programming menu of the system. It is required to put the
system to programming mode to get access to the settings.
Entering the programming mode
You can enter the programming mode only if the base unit is powered
form USB socket or from an external power supply, the ignition is off, the sys-
tem is disarmed and the service mode is switched off.
Enter the programming mode by entering the ‘Service PIN-code’ (factory
preset is 1-1-1-1). The PIN-code should be entered using an external or located
on the base unit VALET button. The input is indicated by flashes of an external
or located on the base unit LED indicator.
The system stops to perform control commands while it is in the program-
ming mode.
Note! see the “coNtRol oveR the system IN cAse of emeRGeNcy” sectIoN foR
descRIptIoN of the pIN-code eNteRING pRoceduRe.
Note! If theRe Is No ‘seRvIce pIN-code’, you cAN eNteR the pRoGRAmmING mode
usING the ‘secRet pIN-code’ WRItteN oN the oWNeR’s cARd
WARNING! It Is pRohIbIted to eRAse the pRotectIve lAyeR oN the oWNeR’s cARd.
the INfoRmAtIoN oN the cARd Is INteNded oNly foR the oWNeR of the system.
Exiting the programming mode
There are several ways to exit the programming mode:
Switch on the ignition
Press and hold the VALET button more than 10 seconds (until a siren sound)
Disconnect power of the base unit (disconnect the main power supply and USB)
The system will reboot programmatically (all changes will be saved) after
exiting programming mode. All ways to exit the programming menu are ac-
companied by sound signals of the siren and light signals of the LED indicator.
The signals indicate the number of recorded control devices
