USING THE PANTHER ™ LS8EQ
13
The Home Screen
The home screen is where you enter and edits text or place label items known as
tools. The home screen is also where you print labels. The home screen has
several different indicators, including:
INDICATOR ICON DESCRIPTION
Caps Lock
Indicates if caps lock is on or off.
Shift Function
or
Indicates if the shift key has been pressed.
Label Mode
Indicates current label mode.
Text Size Indicates the text size for the current line.
Text Style
A
B
B
Indicates the text style for the current cursor
position. Available styles include Normal (no
icon), Normal + Underline, Bold, and Bold +
Underline.
Text Line
Indicates the current line.
Page
1:9
Indicates the current page. There are 9 total
pages.
Vertical or
Horizontal Line
Indicates that a label has one or more dividing
lines selected.
Frame
Indicates that a label has a frame selected.
Low Battery
Indicates that battery voltage is low and that
batteries need replacing.
The Tools Menu
The tool menu includes serializations, symbols, data lists, bar codes, and
date/time stamps. These items are placed on the home screen. The tool menu is
accessed by pressing the Insert Tools key.
Tool Icons
The following icons represent the available tools:
- Serialization
- Symbol
- Data List
- Barcode
- Date Stamp
- Time Stamp

Panduit PanTher LS8EQ Specifications

General

Color	-
Print technology	Thermal transfer
Vertical printing	Yes
Maximum resolution	203 x 203 DPI
Maximum print height	- mm
Display	LCD
Product color	Black, Grey
Keyboard layout	QWERTY
Display number of lines	4 lines
Certification	RoHS, WEEE, FCC
Number of styles	3
Battery type	AA
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Number of batteries supported	6
PC connection	USB 2.0
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	0 - 90 %
Cables included	USB
Bundled software	PanTherLink

Weight and Dimensions

Weight	80 g
