Panduit PanTher LS8EQ User Manual

PRINTER CLEANING INSTRUCTIONS
63
Cleaning the Print head and Drive Roller
The LS8EQ printer is cleaned using the LS8-CLN cleaning kit.
The print head should be cleaned regularly, and more often in harsh
environments. The print head should be cleaned whenever any irregular printing
results occur. The drive roller should be cleaned whenever foreign matter, such
as dust or adhesive, is present.
1. Turn OFF power to printer.
2. Remove the cassette door.
3. Unlock the print head latch.
4. Remove the label cassette from the printer
5. Rub a cotton swab with cleaning solution along the print head.
6. Repeat until no more residue is picked up by the swab.

Panduit PanTher LS8EQ Specifications

General

Color	-
Print technology	Thermal transfer
Vertical printing	Yes
Maximum resolution	203 x 203 DPI
Maximum print height	- mm
Display	LCD
Product color	Black, Grey
Keyboard layout	QWERTY
Display number of lines	4 lines
Certification	RoHS, WEEE, FCC
Number of styles	3
Battery type	AA
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Number of batteries supported	6
PC connection	USB 2.0
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	0 - 90 %
Cables included	USB
Bundled software	PanTherLink

Weight and Dimensions

Weight	80 g
