Panduit PanTher LS8EQ User Manual

APPLICATION BASED LABEL WIZARD (F4)
62
Using the TIA/EIA-606-A Compliance Tool in the Label Wizard
1. From within the Label Wizard, select TIA for TIA/EIA-606-A.
2. Use the right and left arrow keys to select the required class (class 1,
class 2, class 3, or class 4).
3. Press ENTER.
4. Use the right and left arrow keys to scroll between TIA labeling
applications.
5. Press ENTER for the selected TIA application.
6. Use the right and left arrow keys to scroll within the parameters of each
TIA application.
7. Press ENTER for the selected parameter. An on-screen window will
appear.
8. Type the value for the selected parameter in the on-screen window.
9. Press ENTER.
10. Repeat steps 6-9 for each parameter.
11. Press Shift and then F10 to save the serialization and exit the Label
Wizard.
12. The TIA compliant labels that you have created are stored in a data file.
The data tool appears on the home screen. To edit this file, highlight the
icon on the home screen, press SHIFT, and press the INSERT key.
13. Press F4 to restart the Label Wizard for a new TIA compliant labeling
application.
14. The TIA compliance tool in the LS8EQ printer is similar to the TIA/EIA-
606-A label wizard function within Easy-Mark™ labeling software.

Panduit PanTher LS8EQ Specifications

General

Color	-
Print technology	Thermal transfer
Vertical printing	Yes
Maximum resolution	203 x 203 DPI
Maximum print height	- mm
Display	LCD
Product color	Black, Grey
Keyboard layout	QWERTY
Display number of lines	4 lines
Certification	RoHS, WEEE, FCC
Number of styles	3
Battery type	AA
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Number of batteries supported	6
PC connection	USB 2.0
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	0 - 90 %
Cables included	USB
Bundled software	PanTherLink

Weight and Dimensions

Weight	80 g
