Pantum P2500 Series Maintenance Manual

6–13
P8 Abnormal high-voltage output
Possible cause
Solution
The power cord is not plugged in or is
damaged.
Make sure the power cord is connected
correctly.
The high-voltage contact is dirty.
Clean the high-voltage contact.
The high voltage power board is faulty.
Replace the high voltage power board.
P9 USB cannot be identified by the PC
Possible cause
Solution
The power cord is not plugged in, is poorly
connected, or is damaged.
Make sure the power cord is connected
correctly.
USB cable is poorly connected or
damaged.
Make sure the USB cable is connected
correctly.
The USB interface of the master board is
faulty
Replace the master board.
The master board is faulty.
Replace the master board.
P10 Page prints gibberish or whole page is dark
Possible cause
Solution
USB cable is loose or damaged
Make sure the USB cable is connected
correctly.
FFC cable connection between the high
voltage power board and the master
board is bad or unreliable.
Replace the master board
The master board is damaged.
Replace the master board.

Pantum P2500 Series Specifications

General

Print Technology	Monochrome Laser
Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	15, 000 pages
Input Capacity	150 sheets
Output Capacity	100 sheets
Connectivity	USB 2.0
Dimensions	337 x 220 x 178 mm
Processor Speed	600 MHz
Memory	128 MB
Print Speed	22 ppm (A4)
First Print Out Time	Less than 7.8s
Operating System Support	Windows, Mac, Linux
Media Sizes	A4, A5, A6, Letter, Legal, Executive
Media Types	Plain, Thick, Cardstock, Label, Envelope, Thin
Media Weight	60 - 163 g/m²
