Paradox Digiplex EVO PRT3 User Manual

13
Request Area Status
The following commands request the area status. For the panel’s maximum number of areas, refer to “Panel Specifications” on page1.
The Request Area Status command involves an information request. When the command is valid, the first five characters of the command
are returned followed by the requested information. The following provides an example of the information sent by the Printer Module to the
home automation module after having received a Request Area Status 01 command:
Request Zone Status
The following commands request the zone status. For the panel’s maximum number of zones, refer to “Panel Specifications” on page1.
The Request Zone Status command also involves an information request. When the command is valid, the first five characters of the
command are returned followed by the requested information. The following provides an example of the information sent by the Printer
Module to the home automation module after having received a Request Zone Status 01 command.
Request Zone Label
The following commands request the zone label. For the panel’s maximum number of zones, refer to “Panel Specifications” on page 1.
The Request Zone Label command also involves an information request. When the command is valid, the first five characters of the
command are returned followed by the requested zone label. All zone labels are 16 characters in length.
Byte 1 Byte 2 Byte 3 Byte 4 Byte 5 Byte 6
Request Area Status 01
RA001<cr>
Request Area Status 02
RA002<cr>
LL
Request Area Status 08
RA008<cr>
Byte 1 Byte 2 Byte 3 Byte 4 Byte 5 Byte 6 Byte 7
RA0 01
D (Disarmed)
A (Armed)
F (Force armed)
S (Stay armed)
I (Instant armed)
M (Zone in
memory)
O (Ok)
Byte 8 Byte 9 Byte 10 Byte 11 Byte 12 Byte 13
T (Trouble)
O (Ok)
N (Not ready)
O (Ok)
P (In
programming)
O (Ok)
A (In alarm)
O (Ok)
S (Strobe)
O (Ok)
<cr>
Byte 1 Byte 2 Byte 3 Byte 4 Byte 5 Byte 6
Request Zone Status 01
R Z 0 0 1 <cr>
Request Zone Status 02
R Z 0 0 2 <cr>
LL
Request Zone Status 192
R Z 1 9 2 <cr>
Byte 1 Byte 2 Byte 3 Byte 4 Byte 5 Byte 6
RZ001
C (Closed)
O (Open)
T (Tampered)
F (Fire loop trouble)
Byte 7 Byte 8 Byte 9 Byte 10 Byte 11
A (In alarm)
O (Ok)
F (Fire alarm)
O (Ok)
S (Supervision lost)
O (Ok)
L (Low battery)
O (Ok)
<cr>
Byte 1 Byte 2 Byte 3 Byte 4 Byte 5 Byte 6
Request Zone Label 01
ZL001<cr>
Request Zone Label 02
ZL002<cr>
LL
Request Zone Label 192
ZL192<cr>
