System Events
All Digiplex system events are sent through the Printer Module to the home automation module using the following format.
* xxx represents the 3-digit event group (G).
** yyy represents the 3-digit event number (N).
*** zzz represents the 3-digit area number (A). Area number 000 signifies that the event has occurred in all enabled areas or is a global
event independent of area assignment.
As shown above, system events involve a 3-digit event group (Gxxx), a 3-digit event number (Nyyy) and a 3-digit area number (Azzz). The
following table lists the event group and event number descriptors that can be used to read the system event format. For example,
G001N005A006 means zone 5 in area 6 has been opened. (Event group 001= Zone open, Event number 005= zone 5, Area 006= area 6).
Byte 1 Bytes 2-4 Byte 5 Bytes 6-8 Byte 9 Bytes 10-12
System Event
G xxx* N yyy** A zzz***
Event
Group (G)
Event Group Description Event Number (N) Event Number Description Area Number (A)
000 Zone is OK
001-192 Zone Numbers 001-008
001 Zone is Open
002 Zone is Tampered
003 Zone is in Fire Loop Trouble
004 Non-reportable Event
000 TLM Trouble
000-008
001 Smoke detector reset
002 Arm with no entry delay
003 Arm in Stay mode
004 Arm in Away mode
005 Full arm when in Stay mode
006 Voice module access
007 Remote control access
008 PC Fail to communicate
009 Midnight
010 NEware User Login
011 NEware User Logout
012 User Initiated Callup
013 Force Answer
014 Force Hangup
005
User Code entered on
Keypad
000-999 User Codes 000-008
006 User/Card Access on door 001-032 Door Numbers 000-008
007
Bypass Programming
Access
000 One-touch Bypass Programming
001-008
001-999 User Code
008 TX Delay Zone Alarm 001-192 Zone Numbers 001-008
009 Arming with Master 001-999 User Codes 001-008
010 Arming with User Code 001-999 User Codes 001-008
011 Arming with Keyswitch 001-032 Keyswitch numbers 001-008
